powerful USHIO red laser diodes target laser tv and laser projection

powerful USHIO red laser diodes target laser tv and laser projection

high output power improves image quality

PRESS RELEASE: October 2017

The Optoelectronics Company is delighted to announce that USHIO’s new high-power laser diodes, the HL63283HD and HL63290HD, are now mass production. These two new diodes offer laser TV and laser projector manufacturers the massive optical power output they need to enhance image quality with more vivid colour and greater clarity in a competitive and increasingly sophisticated market.

USHIO HL63283HD specifications

The USHIO HL63283HD is a visible wavelength laser diode in a 9mm diameter CAN package with high heat dissipation and high wall plug efficiency of 40%. It offers a massive 1.2W optical output power at a typical centre lasing wavelength of 637nm at 25 degrees Centigrade. Its operating temperature range is -10 to +45 degrees Centigrade, typical operating voltage is 2.3V, LD reverse voltage is 2V with a typical threshold current of 340mA and operating current of 1300mA. The typical beam divergence parallel to the junction is 10 degrees, perpendicular to the junction is 33 degrees.

download data sheet >

USHIO HL63290HD specifications

The USHIO HL63290HD is also a visible wavelength laser diode in a 9mm diameter CAN package with high heat dissipation and high wall plug efficiency of 40%. However, it offers even more optical output power :2.2W CW at a typical centre lasing wavelength of 638nm at 25 degrees Centigrade. Its operating temperature range is -10 to +55 degrees Centigrade, typical operating voltage is 2.4V, LD reverse voltage is 2V with a typical threshold current of 600mA and operating current of 2.4A. The typical beam divergence parallel to the junction is 10 degrees, perpendicular to the junction is 33 degrees.

download data sheet >

highest output power remains critical

“The march toward higher and higher power laser diodes shows no signs of slowing down”, said Tony Pope, M.D., the Optoelectronics Company. “High power red laser diodes remain critical to achieve the vivid colour, brightness and image quality required for laser TV and laser display applications nowadays. These two new USHIO red laser diodes enable overall output power to be maximised without increasing the number of components”.

high wall plug efficiency rate saves energy

Notwithstanding their optical output power, both diodes offer a high wall-plug efficiency rate of 40 per cent which reduces both their electrical power consumption and the amount of heat that must be removed from the package. High wall-plug efficiency, particularly for high-power lasers, is vital as it not only reduces energy consumption but also reduces the demands on electrical installations and on the cooling system, resulting in a reduction of the size of the laser system. This allows for a more compact and integrated design, vital as manufacturers compete to produce the most streamlined and beautiful TVs and tiny projectors.

Both the USHIO HL63283HD and HL63290HD are currently in full production to meet growing demand.

USHIO laser diodes

All USHIO high performance laser diodes are available from the Optoelectronics Company. Please contact the Optoelectronics Company to request samples for testing.

about USHIO

USHIO OPTO SEMICONDUCTORS, INC. manufactures world class laser diodes and other optical devices utilising their unique laser technologies and manufacturing expertise. The product line-up includes high power red laser diodes for displays, red laser diodes for medical and measurement applications, violet laser diodes for exposure equipment and infrared emitting diodes for optical encoders.

USHIO’s high performance laser diodes are proven to consume a low operating current which extends battery life whilst maintaining the integrity of the laser diode power in a variety of applications such as inspection, measurement and biomedical applications and as a light source for optical equipment.

All USHIO diodes are RoHS compliant.
